WEST 8800 - Configuration Parameters

Configuration level
Configuration parameters 44 8800 process controller
Name Value range Description Default
Err.r
Reset of all error list entries
0
0
no function (switch-over via interface is possible)
2
DI1 switches
3
DI2 switches (only visible with OPTION)
4
DI3 switches (only visible with OPTION)
5
è - key switches
6
Ò - key switches
Pid.2
Switching of parameter set (Pb, ti, td)
0
0
no function (switch-over via interface is possible)
2
DI1 switches
3
DI2 switches (only visible with OPTION)
4
DI3 switches (only visible with OPTION)
5
è - key switches
I.Chg
Switching of the actual process value between Inp1 and X2
0
0
no function (switch-over via interface is possible)
2
DI1 switches
3
DI2 switches (only visible with OPTION)
4
DI3 switches (only visible with OPTION)
5
è - key switches
di.Fn
Function of digital inputs (valid for all inputs)
0
0
direct
1
inverse
2
toggle key function
fDI1
Forcing di1 (only visible with 8800/8840 configurator!)
0
0
No forcing
1
Forcing via serial interface
fDI2
Forcing di2 (only visible with 8800/8840 configurator!)
0
0
No forcing
1
Forcing via serial interface
fDI3
Forcing di3 (only visible with 8800/8840 configurator!)
0
0
No forcing
1
Forcing via serial interface
othr
Name Value range Description Default
bAud
Baudrate of the interface (only visible with OPTION)
2
0
2400 Baud
1
4800 Baud
2
9600 Baud
3
19200 Baud
Addr
1...247
Address on the interace (only visible with OPTION)
1
