Configuration level
Configuration parameters 32 8800 process controller
Name Value range Description Default
S.tYP
Sensor type selection
1
0
thermocouple type L (-100...900°C) , Fe-CuNi DIN
1
thermocouple type J (-100...1200°C) , Fe-CuNi
2
thermocouple type K (-100...1350°C), NiCr-Ni
3
thermocouple type N (-100...1300°C), Nicrosil-Nisil
4
thermocouple type S (0...1760°C), PtRh-Pt10%
5
thermocouple type R (0...1760°C), PtRh-Pt13%
6
thermocouple type T (-200...400°C), Cu-CuNi
7
thermocouple type C (0...2315°C), W5%Re-W26%Re
8
thermocouple type D (0...2315°C), W3%Re-W25%Re
9
thermocouple type E (-100...1000°C), NiCr-CuNi
10
thermocouple type B (0/100...1820°C), PtRh-Pt6%
18
special thermocouple
20
Pt100 (-200.0 ... 100,0 °C)
21
Pt100 (-200.0 ... 850,0 °C)
22
Pt1000 (-200.0 ... 850.0 °C)
23
special 0...4500 Ohm (preset to KTY11-6)
24
special 0...450 Ohm
30
0...20mA / 4...20mA 1
40
0...10V / 2...10V 1
41
special -2,5...115 mV 1
42
special -25...1150 mV 1
50
potentiometer 0...160 Ohm 1
51
potentiometer 0...450 Ohm 1
52
potentiometer 0...1600 Ohm 1
53
potentiometer 0...4500 Ohm 1
S.Lin
Linearization (only at S.tYP = 23 (KTY 11-6), 24
(0...450 ), 30 (0..20mA), 40 (0..10V), 41 (0...100mV) and
42 (special -25...1150 mV))
0
0
none
1
Linearization to specification. Creation of linearization table
with 8800/8840 configurator (engineering tool) possible.
The characteristic for KTY 11-6 temperature sensors is
preset.
Corr
Measured value correction / scaling
0
0
Without scaling
1
Offset correction (at CAL level)
2
2-point correction (at CAL level)
3
Scaling (at PArA level)
In.f
-1999...9999
Alternative value for error at INP1
OFF
fAI1
Forcing INP1 (only visible with 8800/8840 configurator!)
0
0
No forcing
1
Forcing via serial interface
1 with current and voltage input signals, scaling is required (see chapter 5.3)
