Configuration level
Configuration parameters 42 8800 process controller
Name Value range Description Default
O.Src
Signal source of the analog output OUT4 (only visible when
O.TYP=1..5)
0
0
not used
1
controller output y1 (continuous)
2
controller output y2 (continuous)
3
process value
4
effective set-point Weff
5
control deviation xw (process value - set-point)
6
measured value position feedback Yp
fOut
Forcing OUT1 (only visible with 8800/8840 configurator!)
0
0
No forcing
1
Forcing via serial interface
Out.5
Configuration parameters Out.2 = Out.1 except for: Default Y.1 =0 Y.2 =0
Out.6
Configuration parameters Out.2 = Out.1 except for: Default Y.1 =0 Y.2 =0
g
Method of operation and usage of output Out.1 to Out.6:
Is more than one signal chosen active as source, those signals are
OR-linked.
LOGI
Name Value range Description Default
L_r
Local / Remote switching (Remote: adjusting of all values
by front keys is blocked)
0
0
no function (switch-over via interface is possible)
1
always active
2
DI1 switches
3
DI2 switches (only visible with OPTION)
4
DI3 switches (only visible with OPTION)
5
è - key switches
SP.2
Switching to second setpoint SP.2
0
0
no function (switch-over via interface is possible)
2
DI1 switches
3
DI2 switches (only visible with OPTION)
4
DI3 switches (only visible with OPTION)
5
è - key switches
