SPECIFICATIONS
42
PARAMETER iGen1200 iGen2200 iGen2500 iGen4500s
ENGINE
Type
1-Cylinder, 4-Stroke, Overhead Valve, Air Cooled
Displacement (cm
3
) 54 79 98 224
Max. Speed (rpm) 5,200 5,300 5,500 3,600
Oil Capacity (mL) 250 350 350 600
Low Oil Shutdown Yes Yes Yes Yes
Spark Plug Torch A5RTC Torch E6RTC Torch E6RTC Torch F7RTC
Fuel Unleaded Petrol
Fuel Tank Capacity (L) 2.8 4.3 4.3 13.5
Fuel Gauge No No No Yes
Starting Method Recoil Recoil Recoil Electric
Battery Included N/A N/A N/A Yes
240 V AC
ELECTRICAL
Voltage (V)
240 240 240 240
Frequency (Hz)
50 50 50 50
No. of Phases
1 1 1 1
Continuous Running Power (W)*
1,000 1,800 2,200 3,700
Maximum Starting Power (W)
1,200 2,200 2,500 4,500
Continuous Running Current (A)
4.2 7.5 9.2 15.4
Voltage & Waveform Control Digital Inverter, Pure Sine Wave Output
Receptacle(s) 1 x 15 A, IP44 1 x 15 A, IP44 1 x 15 A, IP44 2 x 15 A, IP44
Overload Protection Electronic
Alternator Brushless, Permanent Magnet
Output Power Meter No No No Yes
12 V DC
ELECTRICAL
Voltage (V) 12 N/A N/A 12
Maximum Current (A) 5 N/A N/A 8
Maximum Power (W) 60 N/A N/A 100
Receptacle 1 x 5 A, IP44 N/A N/A 1 x 8 A, IP44
5 V DC
ELECTRICAL
Voltage (V) 5 5 5 5
Maximum Current (A) 2.1 2.1 2.1 2.1
Maximum Power (W) 10 10 10 10
Receptacle USB Type A, IP44
DIMENSIONS
& WEIGHT
Length (mm) 463 500 500 650
Width (mm) 262 285 285 480
Height (mm) 395 450 450 520
Weight - Dry (kg) 15 21 21.5 49.5
Weight - Wet (kg) 17 24.5 25 60
* Rated output at 1.0 power factor.

Westinghouse iGen2500 Specifications

General

Running Watts	2200
Peak Watts	2500
Fuel Type	Gasoline
Noise Level	52 dBA
Weight	48 pounds
Tank Capacity	1.0 gallon
Engine	98cc Westinghouse Engine
Outlets	2 x 120V 20A
