Whirlpool 465 - Electric Range Component Locations

- 23 -
ELECTRIC RANGE COMPONENT
LOCATIONS
OPEN COIL
ELEMENT
HOT SURFACE
INDICATOR
(CERAN GLASS
MAINTOP)
BROIL ELEMENT
ELECTRONIC
OVEN CONTROL
OR MECHANICAL OVEN
THERMOSTAT
SURFACE
ELEMENT CONTROL
SURFACE ELEMENT
(CERAN GLASS MAINTOP)
BAKE ELEMENT
OVEN TEMP SENSOR*
THERMO-BULB**
AUTOMATIC
OVEN LIGHT
SWITCH
OVEN LIGHT
MANUAL
OVEN LIGHT
SWITCH
(SOME MODELS)
OVEN
THERMAL FUSE
• For a description and test procedure for the Oven Temperature Sensor, refer to the previous page.
