Whirlpool 465 - Electric Range Strip Circuits; Bake Circuit; Broil Circuit; Self-Clean Circuit

- 26 -
ELECTRIC RANGE STRIP CIRCUITS
EZ-200 & EZ-300 Oven Controls
L1
L2
BK
BK
RR
BROIL ELEMENT
BAKE ELEMENT
BU
BU-W
R
THERMAL FUSE
OPENS @ 184˚C
BROIL
RELAY
OVEN CONTROL
BAKE
RELAY
P2-2 P2-1
P2-4
P2-3
OR P6
BAKE CIRCUIT
L1
L2
BK
BROIL ELEMENT
BU
BU-W
R
THERMAL FUSE
OPENS @ 184˚C
BROIL
RELAY
OVEN CONTROL
P2-2 P2-1
BROIL CIRCUIT
DOOR LATCH
SWITCH
DOOR
SWITCH
L1
L2
N
BK
BK
Y
Y
RR
R
BR
W
W
OVEN CONTROL
TRANSFORMER
BROIL ELEMENT
BAKE ELEMENT
LATCH RELAY
BU
BU
BU
BU-W
OVEN TEMP
SENSOR
R
THERMAL FUSE
OPENS @ 184˚C
DOOR LATCH
SOLENOID
BROIL
RELAY
BAKE
RELAY
P4-1
P4-5
P2-2 P2-1
P2-4
P3-1 P3-2
P3-4
P3-7
P2-3
OR P6
P4-3
V
V
P3-3
P3-6
SELF-CLEAN CIRCUIT
