PAGE 26
FOR SERVICE TECHNICIAN’S USE ONLY
DO NOT REMOVE OR DESTROY
IMPORTANT: Electrostatic discharge may cause damage to machine control electronics. See page 1 for ESD information.
GAS DRYER WIRING DIAGRAM
Figure 15 - Wiring Diagram, Gas
