Thermistor and Possible Frost Build-Up (Continued)
10. If you see frost build-up on the freezer drawer check for
freezer door alignment. Also check the right side rail bracket
assembly for the gap in the gears at the rear. If you do not see
the Gap shown in replace it with the part number included in.
Aer replacing the right side rail bracket re-check the door
alignment to the cabinet. When the drawer is fully closed, the
teeth on the gear are posioned in the void in the adapter,
see . When the drawer is opened there is a slight delay before
the gear teeth engage the teeth on the adapter. If the drawer
is opened o center the le side of the drawer may engage
before the right side giving the impression that drawer is
loose or crooked.
Model  
WRF992FIF* W10682494 Rev G W10882906
WRF993FIF* W10682494 Rev G W10882906
WRF995FIF* W10682494 Rev G W10882906
NOTE: For models built prior to 2/28/2017 with frost in freezer.
Replace the right side drawer rail bracket assembly with part
number W10888665, right side adapter modied by removing
teeth in rear, producing a beer cabinet to door dimension
leading to improved sealing.
W10888665 Adapter-RH, White, FD, FC
No Teeth in This Area
