QUICK REFERENCE GUIDE
Platinum Split Evaporator Unit (Fan Coil Unit) Front / Side View
Platinum Split Evaporator Unit (Fan Coil Unit) Rear / Side View
°
F
Controller
Filter Grille
Evaporator Unit (Fan Coil Unit)
Circular Connection
Mounting Location
INSIDE CELLAR
Option 2
THROUGH THE WALL
Option 1
Knock Out For Wiring
Knock Out For Wiring
Knock Out For Drain Line
Suction Line Knock Out
Liquid Line Knock Out
Mounting Key Hole (X4)
Knock Out For Suction Line
Knock Out For Liquid Line
Knock Out For Drain Line
