Congratulations on your new Whynter product. To ensure proper operation, please read this Instruction Manual carefully before
using this product. Keep this manual in a safe place for future reference.
Model # : ARC-101CW
INSTRUCTION MANUAL
WHYNTER COOLSIZE 10000 BTU COMPACT
PORTABLE AIR CONDITIONER

Table of Contents

Questions and Answers

  • S
    stewartantonioJul 27, 2025
    How to fix Whynter ARC-101CW Air Conditioner that does not turn on?
    • K
      Kristy HutchinsonJul 27, 2025
      If your Whynter Air Conditioner doesn't turn on, several factors could be at play. First, check for a power outage or tripped breaker and restore power. Ensure the unit is on a circuit with the correct voltage. If the L.C.D.I. power plug is tripped, press the Reset button. Also, if the internal water reservoir is full, drain the water. In case the power cord is damaged, call for service. Only authorized personnel should replace a damaged power cord or power plug.
  • J
    Julia HuntAug 2, 2025
    Why Whynter Air Conditioner turns on but is not cooling?
    • S
      Stephanie IngramAug 2, 2025
      If your Whynter Air Conditioner is running but not cooling, it could be due to several reasons. Ensure the room temperature is within the unit's operational range of 64°F to 90°F. Select the Cooling mode on the display. Allow the compressor 3 minutes to start after selecting Cooling mode. Lower the set temperature, ideally at least 5°F below the ambient temperature. If the internal water reservoir is full and a warning light appears, drain the water manually or run the fan-only mode to exhaust the water.
  • C
    Carl PetersAug 7, 2025
    What to do if Whynter ARC-101CW Air Conditioner is not cooling enough?
    • K
      Kathy MeyerAug 8, 2025
      If your Whynter Air Conditioner isn't cooling the room effectively, start by closing all windows and doors. Reduce the number of people in the room, or consider using additional cooling. Minimize direct sunlight by closing curtains or blinds. If the room is a kitchen or contains heat-producing appliances or a server, you might need additional cooling. Also, if the room is too large for the unit's capacity, consider an additional air conditioner.
  • R
    rharveyAug 14, 2025
    What to do if Whynter ARC-101CW Air Conditioner is leaking water?
    • F
      flynnpennyAug 14, 2025
      If your Whynter Air Conditioner is leaking water, make sure the unit is leveled. If the water tank is full, drain the water from the drain plug at the back of the unit.
  • N
    nsandersAug 20, 2025
    Why fan speed cannot be changed on Whynter Air Conditioner?
    • M
      mayerzacharyAug 20, 2025
      The fan speed difference is not very noticeable when the compressor is on. Try setting the Whynter Air Conditioner to Fan only mode, you should be able to hear the difference between high and low fan speed settings.

Summary

Disposal Information

Safety Precautions

Introduction and Technical Data

How It Works

Explains the functional principles and benefits of the portable air conditioner.

Technical Data

Provides detailed specifications including model, cooling capacity, power, and dimensions.

Parts Identification

Control Panel

Control Panel Overview

Details the functions of the LCD display, buttons, and indicators on the control panel.

Installation

Water Drainage

Explains manual and continuous methods for draining accumulated water from the unit.

Location and Exhaust Hose Installation

Guidance on proper unit placement and connecting the exhaust hose.

Window Kit Installation

Instructions for installing the window kit to vent the exhaust hose through a window.

Operation Instructions

Switching On;Off and Modes

Covers powering the unit on/off and selecting modes like Cool, Dehumidify, and Fan.

Timer Functionality

Explains how to set delayed switch ON/OFF timers for the air conditioner.

Noise and Compressor Lock Out

Describes normal operating sounds and the compressor's 3-minute start delay.

Remote Control

Installing Batteries and Operation

Instructions for inserting batteries and operating the remote control.

Care and Maintenance

Cleaning Air Filters

Steps for cleaning the washable pre-filter and replacing the activated carbon filter.

Cleaning the Unit and Storage

Guidance on wiping the unit and preparing it for end-of-season storage.

Troubleshooting

Common Problems and Solutions

Addresses issues like unit not turning on, no cooling, and weak airflow.

Additional Troubleshooting

Covers problems such as insufficient cooling, noise, leaks, and fan speed issues.

Warranty Information

Whynter ARC-101CW Specifications

General IconGeneral
Typeportable
Colorwhite
Operating Area Size300 square feet
Cooling Settings1
Seasonally Adjusted Cooling Capacity5214.9 british thermal units
Heaterno
Fan Airflow Rate145 cubic feet per minute
Filtercarbon
Hosesingle
Remote Controlyes
Timeryes
Sleeping Modeno
Current9.4 amperes
