Whynter ARC-12SD User Manual

9 | P a g e
INSTALLATION INSTRUCTIONS
Location
The air conditioner should be placed on a hard and level surface strong enough to support the
unit. The unit has casters and it should only be rolled on smooth, flat surfaces. Use caution
when rolling on carpet surfaces. Do not attempt to roll the unit over objects.
Never place any obstacles around the air inlet or outlet and allow at least 20 inch of clearance
for efficient air-conditioning.
Exhaust hose Installation
When you use this air conditioner unit, hot air must be exhausted out of the room to complete
the air exchange of the condenser. When the unit is operating in DEHUMIDIFYING or FAN only
mode, no exhaust is required.
1. Pull out about 6” of one end of the hoses.
2. Attach the hose connectors to the hoses by turning clockwise.
3. Align the slots on the hose connector to the tabs on the air intake / outlet and snap the
hose to the unit.
4. Only extend the exhaust hoses to the necessary length. We do not
recommend extending the exhaust hose more than 9' long. Additional 4’
exhaust hose sold separately.
* If you are interested in purchasing optional accessories, please contact
info@whynter.com for retail sales information.
INTAKE
EXHAUST

Whynter ARC-12SD Specifications

General

Type	portable
Color	platinum, silver
Operating Area Size	400 square feet
Cooling Settings	1
Seasonally Adjusted Cooling Capacity	4959 british thermal units
Heater	no
Moisture Removal	91 pints per day
Fan Speeds	3
Fan Airflow Rate	188 cubic feet per minute
Filter	carbon
Hose	single
Noise Level	53 decibels adjusted
Remote Control	yes
Wireless Connectivity	none
Timer	yes
Sleeping Mode	no
Control Type	touchpad
Energy Efficiency	11.11
Voltage	115
Current	9.5 amperes
Depth	15.5 inches
Height	31 inches
Width	17 inches
Net Weight	62 pounds
