Model Number ARC-14D ARC-14H
Cooling Capacity 14,000 BTU/hr 14,000 BTU/hr
Heating Function N/A Included
Cooling Power Consumption 1100 W / 9.8 A 1100 W / 9.8 A
Humidity Removal Capacity 80 pints / Day 80 pints / Day
Recommended room size Up to 400 sq. ft. Up to 400 sq. ft.
Power Supply 115V / 60Hz / 1 Phase 115V / 60Hz / 1 Phase
Compressor Rotary Rotary
Refrigerant R-22 R22
Fan Speed 3 (2 + 1 Turbo) 3 (2 + 1 Turbo)
Temperature Set Range 64°F - 90°F 64°F - 90°F
Timer 0-24 hours 0-24 hours
Weight 75 lbs. 75 lbs
Dimensions 20"W x 16"D x 33"H 20"W x 16"D x 33"H
REMARKS:
The cooling capacity of the unit may be affected
by the height of the ceiling, quality of insulation,
number of windows, etc.
2
NOTE: A proper balance between temperature and humidity is critical to maintain a comfortable
living environment. If humidity is high, it will be necessary to empty the internal water container
frequently, until the ideal humidity is reached.
When the internal water container is full, the back light on the LCD display flashes.
The unit will shut off automatically, and must be drained before it will restart.
To Drain the Unit:
• Switch off the unit and remove the plug from the wall socket.
• DO NOT MOVE THE UNIT. Doing this can result in water
leakage, damaging your floor or carpet.
• Place the drain pan on the floor under the drain cap.
• Remove the drain cap and the rubber stopper from the
drain, and let the water run out. Partially fill the drain pan,
replace the rubber stopper, and empty the drain pan.
This procedure must be repeated until the unit is empty.
• Replace the rubber stopper and drain cap.
Put plug into the wall socket, and switch the unit on.
The warning signal should be off.
For Continuous Drainage:
• Switch off the unit and remove the plug from the electrical outlet.
• Remove the Drain Cap and Rubber Stopper. Drain if necessary.
• Connect a Drain Tube (not included) (20mm / 3/4" inner dimension) on to the water outlet.
• Place the other end in a drain. Make sure the tube is free from twists and bends.
The tube must decline over its entire length.
NOTE: When restarting the unit it may take up to 3 minutes for the compressor to turn on.
11
Specifications Emptying the Internal Water Container
