4.6. Support
With the support you can support fittings. For long part you can use rotated the support 180°
(right picture).
With clamping lever you fix the support on axis.
You can with an additional guide bar (optional)
use the support either front or rear.
You can with an additional guide bar (optional)
use the support either front or rear (arrow).
Clamping lever
Support
