widos 3511 - Designation of the product

Kunststoffschweißtechnik
Description of product Chapter 1
20.08.14 Working instructions WIDOS 3511 Page 7 of 39
1.4. Designation of the product
The product is designated by a type label at basic machine and heating element.
The labels contain the type of the machine, the serial number and the year of construction.
1.4.1. Technical data
1.4.1.1.
WIDOS 3511 General data
Material: PP, PE, PVDF, PB
Pipe diameter range: OD = 20 - 125 mm (optional up to OD 150mm)
Transport box (l x w x h): 850 x 670 x 680 mm
Total weight: 80 kg
Protection: 16 A
Emissions:
- When using the named pipe materials and when
welding below 260° C or 500° F no toxic damp arises.
Ambient conditions: - Keep the workshop clean (especially the welding area
must be clean)
- If secured by an appropriate measurement that allowed
conditions for welding are indicated, it is possible to
work in any outside temperature condition as far as the
welder is not constrained in its manual skill- Avoid
humidity, if necessary put up a tent
- Avoid strong sun beams
- If it is windy shut the pipe endings
1.4.1.2. Heating element
Power: 1000 Watt 1000 Watt
Voltage: 230 V ( 10%) 110 V ( 10%)
Current: 4,6 A ( 10%) 9,2 A ( 10%)
Wire cross section: 1,5 mm² 1,5 mm²
Frequency: 50 Hz 60 Hz
Attached elements: - electronic temperature
control
- control lamp
- connecting cable with
plug
- electronic temperature
control
- control lamp
- connecting cable with
plug
Weight: approx. 2 kg approx. 2 kg
