Kunststoffschweißtechnik
Spare parts list Chapter 9
Basic machine WIDOS 3511
Pos. Name Piece Order no.
1 Rack down 1 3551029
2 Washer M5 DIN 125 2 0125E
3 Pan-head screw M 5x20 DIN 7984 2 7984E020
4 Stop bolt 1 3751046
5 Shim ring 8 x 14 x 0,5 DIN 988 1 on request
6 Idler 2 3751005
7 Base frame 1 375001
8 Gear shaft 1 3751006
9 Flange bushing PAF18170P10 1 on request
10 Spacer ring 1 3751009
11 Spur gear 1 372107
12 Retaining ring 12 x 1 DIN 471 1 0471L
13 Feather key A 4x4x22 DIN 6885 1 6885D022
14 Cruciform hub, complete 1 3751008KP
15 Bearing pin 1 3751011
16 Shim ring 20 x 28 x 1 DIN 988 1 0988T010
17 Straight pin 3h11 x 12 DIN 7 1 0007C012
18 Spring-loaded thrust pad 615,3-M10-K-PFR 1 on request
19 Streight pin M 10x16 DIN 913 2 0913J016
20 Clamping lever GN212.3-21-M8-25-D 1 on request
21 Pressure piece 1 370120
22 Linit stop washer DVS type A in mm (optional) 1 3751280
(22) Linit stop washer DVS type B in mm (optional) 1 3751250
(22) Linit stop washer ASTM in mm (optional) 1 3751270
(22) Linit stop washer ASTM in inch (optional) 1 3751260
23 Disc 1 3751012
24 Flat-head screw M 6x12 DIN 7991 1 7991F012
25 Washer M8 DIN 125 2 0125H
26 Pan-head screw M 8x65 DIN 912 2 0912H065
27 Idler for heating element 1 3751034
28 Pendulum strip 2 3751036
29 Pan-head screw M 6x25 DIN 912 2 0912F025
30 Breaking wave 1 3751035
31 Pan-head screw M 6x30 DIN 7984 2 7984F030
20.08.2014 Working instruction WIDOS 3511 Page 30 of 39
