Spare parts list Chapter 9
Prism gripping tool for pipes WIDOS 3511
Pos. Name Piece Order no.
1 Idler for slide 2 3751028
2 Slide bush PSM202520A51 8 on request
3 Acme thread spindle 1 3751023
4 Counter nut 1 3751025
5 Shim D10xD16x0,5 DIN 988 1 0988J005
6 Adjustment bushing 1 3751024
7 Adjusting ring 1 3751045
8 Handwheel 1 3751027
9 Slide left 1 3751002
10 Rack upside 1 3751018
11 Pan-head screw M 5x16 DIN 912 2 0912E016
12 Grub screw M 6x10 DIN 914 3 0914F010
13 bearing bush 1 3751026
14 Straght pin 8 m6x24 DIN 6325 8 6325H024
15 Flat-head screw M 8x30 DIN 7991 4 7991H030
16 bush PAP2525 P10 4 on request
17 Support plate 1 3751019
18 Washer M5 DIN 125 2 0125E
19 Pan-head screw M 5x50 DIN 912 2 0912E050
20 Clamping tool pipe side OD 20 to 50 mm 2 3757012
(20) Clamping tool pipe side OD 50 to 125 mm 2 3757011
(20) Clamping tool pipe side OD 64 to 150 mm R 1 3757024
(20) Clamping tool pipe side OD 64 to 150 mm L 1 3757023
21 Guide block pipe side, rear 1 3751041
22 Guide block pipe side, in front 1 3751040
23 Star handle GN6335.2-50-M8-E 2 on request
24 Grub screw M 8x60 DIN 914 2 0913H060
25 Clamping tool pipe side OD 20 - 50 mm 1 3757015
(25) Clamping tool pipe side OD 50 - 125 mm 1 3757014
(25) Clamping tool pipe side OD 64 - 150 mm 1 3757022
26 Clamping tool pipe side OD 20 - 50 mm 1 3757016
(26) Clamping tool pipe side OD 50 - 125 mm 1 3757013
(26) Clamping tool pipe side OD 64 - 150 mm 1 3757021
