Kunststoffschweißtechnik
Spare parts list Chapter 9
Prism clamping tool for fitting WIDOS 3511
Pos. Name Piece Order no.
1 Clamping tool fitting L/R OD 75 - 167 mm 1 3757117
(1) Clamping tool fitting L/R OD 29 - 68 mm 1 3757119
(1) Clamping tool fitting L/R OD 29 - 68 NIBCO 1 3757125
2 Idler for slide 2 3751028
3 Slide bush PSM202520A51 8 on request
4 bearing bush 1 3751026
5 Grub screw M 6x10 DIN 914 3 0914F010
6 Acme thread spindle 1 3751023
7 Slide right 1 3751003
8 Support plate 1 3751019
9 Washer M5 DIN 125 2 0125E
10 Pan-head screw M 5x50 DIN 912 2 0912E050
11 Counter nut 1 3751025
12 Shim 1 0988J005
13 Adjustment bushing 1 3751024
14 Straght pin 8 m6x24 DIN 6325 4 6325H024
15 Flat-head screw M 8x30 DIN 7991 4 7991H030
16 Bush PAP2525 P10 4 on request
17 Guide block pipe side, rear 1 3751043
18 Guide block pipe side, in front 1 3751042
19 Adjusting ring 1 3751045
20 Handwheel 1 3751027
21 Arrester 1 3751004
22 Guide rod arrester 1 (2) 3751032
23 Eccentric clamp GN927-82-M8-A 1 on request
20.08.2014 Working instruction WIDOS 3511 Page 34 of 39
