widos 3511 - Page 36

Kunststoffschweißtechnik
Spare parts list Chapter 9
Heating element WIDOS 3511
Pos. Name Piece Order no.
1 Heating element complete 230V 1 H3511E
(1) Heating element complete110V 1 H3511E110
2 Cylindrical knob 1 0519-26-M12
3 Fixing element 1 3755005
4 Pan-head screw M 6 x 20 DIN 912 2 0912F020
5 Distance bolt 2 3755004
6 Pan-head screw M 6 x 30 DIN 912 2 0912F030
7 Handlebar 335 long 1 3755003
8 Heating plate bracket 1 3755001
9 Guide bearing 2 LKH1630
10 Pan-head screw M 8 x 30 DIN 912 1 0912H030
11 Heating plate 230 V 1 HP3511E
(11) Heating plate 110 V 1 HP3511E110
12 Temperature probe PT 1000 1 H09082
13 Tapped bushing 12x18, M6 2 HGEW-M6
14 Insulating piece 2 371518
15 Pan-head screw M 6 x 90 DIN 912 2 0912HF090
16 Signal lamp green (with low voltage glow lamp) 1 H2105
17 Thermo regulator GZ 4 1 H0918220
18 Control cnob with groove 1 H09075
19 Scale 180-280 °C, d=33 (design 230 V) 1 H09074
(19) Scale 356-536 °F, d=33 (design 110 V) 1 on request
20 Rocker switch red 1 H0903
(20) Rocker switch red (110 V) 1 H0903110
21 Pan head screw M 4x70 DIN 912 3 0912D070
22 Heat sink with Triac BT 139 1 H09081
23 Teflon insulating disk 1 H09091
24 Short handle case 1 H3807
25 Cable bushing PG 11 Skintop BS 1 EVK11BS
26 Mains cable with plug (design 230 V) 1 EK32220
(26) Mains cable with plug (design 110 V) 1 on request
27 Raised coutersunk head screw M 4,2x13 DIN 7981 3 7981D013
20.08.2014 Working instruction WIDOS 3511 Page 36 of 39
