Pos. Name Piece Art.no.
1 Upper clamp 4 071105
2 Outer clamp, fixed 1 071101
3 Inner clamp, fixed 1 071102
4 Inner clamp, movable 1 071103
5 Outer clamp, movable 1 071104
6 Hydraulic cylinder 2 071106
Gasket set for cylinder 2 set D0711061
7 Stop bolt 2 091117
8 Pressure disc 2 071133
9 Pan-head screw M10x25 DIN 912 2 0912J025
10 Protective cap, round 2 J0216
11 Base frame 1 071118
12 Tie rod 2 071107
13 Counter nut M10 DIN 985 2 0985J
14 Flat-head screw M 16x30 DIN 7991 2 7991P030
15 Cylinder head screw M6x10 DIN 912 4 912F010
16 Usitring 6x9,3x1 4 D6x9,3
17 Wascher M8 DIN 125 4 0125H
18 Fluid power cylinder 2 071113
19 Holder for filter 2 093119
20 Hexagon screw M8x20 DIN 933 2 0933H020
21 Filter 2 V092114
22 Screwed connection GE 8 LR 3/8" 2 VXGE8L38
23 Hose bunch, on one side 2 VSCHL5100
24 Hydraulic hose short, left 1 on request
Hydraulic hose simple 1 VSCHL61
Compressed bushing 2 VP256
Bow-shaped nipple 1 VB386
Bow-shaped 45° 1 DKOR6
25 Hydraulic hose short, right 1 on request
Hydraulic hose simple 1 VSCHL61
Compressed bushing 2 VP256
Bow-shaped nipple 1 VB386
Bow-shaped 45° 1 DKOR6
26 Threaded rod 8 071108
27 Nut 8 071109
28 Pressure disc M 14 DIN 6340 8 6340P
29 Rivet 8 071111
30 Lock washer Gr.9 DIN 6799 8 6799I
31 Flat-head screw M 16x30 DIN 7991 6 7991P030
32 Shaft 3 071131
33 Tear-off bar 1 071503
34 Hexagon screw M8x12 DIN 933 2 0933H012
35 Washer M10 DIN 9021 2 9021H
30.06.2011 Working instructions WIDOS 5100 Page 35 / 1 of 45
