Description of product Chapter 1
30.06.11 Working Instructions WIDOS 5100 Page 8 of 45
1.5.1 Technical data
1.5.1.1 WIDOS 5100 General data
Material wich can be welded: PE80, PE 100, PVDF, PP
Pipe diameter range:
∅
outside
= 200 - 450 mm
Dimension transport box (l x w x h):
Weight:
1360 x 1300 x 1005 mm
99 kg
Total weight (without packing): 240 kg
Fuse: 16 A
Wire cross section: 1.5 mm²
Emissions: - Noises exceeding 80 dB (A) may occur; during
planing it is obligatory to wear ear protection!
- When using the named pipe materials and when
welding below 260° C no toxicant damp arises
Environment: - take care for cleanness (no dust at the welding
area)
If secured by an appropriate measurement that
allowed conditions for welding are indicated, it is
possible to work in any outside temperature
condition as far as the welder is not constrained
in its manual skill.
- avoid humidity, if necessary use a welding tent
- avoid strong sun rays influence
- protect from wind, shut the pipe ends
1.5.1.2 Heating element
Power: 3,6 kW
Voltage: 230 V (± 10%)
Current: 15,6 A (± 10%)
Frequency: 50 Hz
Outside-∅ : 500 mm
Surface: nonstick-coated
Attached elements: - Eectronic temperature control
- Control lamps
- Connecting cable with plug
Weight: approx. 20 kg
Due to the high current consumption, the heating element must not be
connected to the aggregate, but to an external plug box with separate fuse
protection.
