Description of product Chapter 1
30.06.11 Working Instructions WIDOS 5100 Page 7 of 45
1.4. Machine overview
1 Planer
2 Heating element
3 Reception box
4 Hydraulic aggregate
5 Basic machine
1.5. Designation of the product
The product is designated by two type labels which are attached at the aggregate and at the
basic machine.
They contain the type, the serial number and the year of construction of the machine.
1
2
3
4
5
