Kunststoffschweißtechnik
Description of product Chapter 1
30.06.11 Working Instructions WIDOS 5100 Page 9 of 45
1.5.1.3 Planer
Motor: Monophase-alternating current-motor
Power: 1400 Watt
Voltage: 230 V (± 10%)
Nominal current: 6.1 A
Frequency: 50 Hz (± 10%)
RPM n2 of planer: 230 revs/min.
Gear: Gear ratio: approx. 0.12
Max. RPM 28 revs / min
Attached elements: - Switch on/off
- Connecting cable with plug
With earthing contact
Weight: Approx. 37 kg
1.5.1.4 Hydraulic aggregate
Power: 0,3 Watt
Voltage: 230 V (± 10%)
Current: 2,7 A
Frequency: 50 Hz
Phase displacement: Approx.18°
Hydraulic oil tank: Approx. 1 l
Protective system: IP 54
Electromotor and pump:
RPM: 1380 (revs / min)
Max. pressure of the pump: Approx. 120 bar
Working pressure: 0 – 100 bar adjustable
Volume velocity: 1.9 l/min
Weight: 23 kg
1.5.1.5 Basic frame
Reduction insert: Dimensions can be selected
Material frame: Machine steel
Material clamping shells: Aluminium
Weight: 109 kg
Cylinder-Ø: 50 mm
Piston rod-Ø: 40 mm
Length of stroke of cylinder: 195 mm
Max. force: (F=P*A) 14140 N (at 100 bar)
Velocity of piston rod: 2.2 cm/s
For article numbers and component parts see spare parts list
