Pos. Name Piece Order no.
1 Cover 1 1010021
2 Pan-head screw M4x12 DIN 912 4 0912D012
3 Motor 1 on request
4 Pump 1,9 l 1 102103
5 Capacitor 12,5 µF 1 EK12220
6 Universal RC - link 1 EE0104
7 Connection cable with plug 1 EK32220
8 Screwed connection PG 13,5 1 EV0113
9 Valve 1 on request
10 Pan-head screw M6x45 DIN 912 4 0912F045
11 Manometer 1 101004
12 Manometer connection 1 V042314
13 Mini hose 1 on request
14 Hose screwing 1 101008
15 Accumulator 1 101006
16 Ring for sealing 16x22,7x1,5 1 D16x22,7
17 Coupling sleeve flat packing 1 VMU14
18 Synthetic cap fVMU14 1 VKM14
19 Coupling plug flat packing 1 VST14
20 Synthetic cap fVMST14 1 VKS14
21 Ring for sealing 16x22,7x1,5 2 D16x22,7
22 Screwed connection 2 V101024
23 O - ring 19x1,5 2 D19x1,5
24 Distributor box 1 on request
25 Pan-head screw M4x10 DIN 912 2 0912D010
26 Socket 2 EST0701
27 Seal, inside 1 1010024
28 Side part 1 1010022
29 Seal, outside 1 1010023
30 Pan-head tapping screw 3,5 x 20 4 7971C020
31 Stick for valve 1 101013
32 Cylinderknob M10 1 101033
33 Boot 1 101035
34 Plate "Pressure loosen" 1 SCHD-L
35 Hexagon nut M10 DIN 934 1 0934J
36 Pressure switch 1 on request
37 Pan-head screw M4x25 DIN 84 2 0084D025
38 Angle for Pressure switch 1 on request
39 Washer M4 DIN 125 1 0125D
40 Pan-head screw M 4x10 DIN 912 1 0912D010
41 Set screw M5x10 DIN 915 1 0915E010
42 Bolt 1 101038
43 Adjusting screw 1 101036
44 Hexagon nut M6 DIN 934 3 0934F
45 Plug-in element P83-1/2"x3/16" 1 101043
30.06.2011 Working instructions WIDOS 5100 Page 38 / 1 of 45
