Kunststoffschweißtechnik
Spare parts list Chapiter 10
Pos. Name Piece Art.no.
1 Frame for terminal box 1 071534
2 Connecting cable 1 EK3220
3 Bolting HKL 2 EVH1313
4 Pan-head screw M 5x25 DIN 912 2 0912E025
5 PTFE-distance washer 2 211508
6 Washer M5 DIN 125 2 0125E
7 Spring washer M5DIN 127 2 0127E
8 Panel 1 071537
9 Control lamp green 1 H2105
10 Plug bolt M6 4 on request
11 Flat head screw M 6x12 DIN 7991 8 7991F012
12 Temperature probe PT 1000 1 H09082
Heating plate 1 HP5100E
Heating plate for change 1 HPT5100E
Terminal box 1 on request
Cover for terminal box 1 on request
16 Control GZ4 with extend axis 1 H0928230
17 Knob for temparature 1 H2109
18 Control lamp yellow 1 H2106
19 PTFE - insolating disk 1 211505
20 Cover plate 1 071536
21 Oval-head screw M3x6 DIN 7985 9 7985C006
22 Handle, kpl. 2 H07021
23 Pan-head screw M 10x40 DIN 912 4 0912J040
24 Handle bolt 4 HGEW-M10
30.06.2011 Working Instructions WIDOS 5100
page 42 of
45
