4. Operating and indicating elements
No. Denomination
1 Bar code reading pen (optional)
2 Display
3 Buttons for operation
4 Drive for the SD card
5 Interface for barcode readind pen
6 Connecting cable
7 Holder for T-pieces
8 - Plug box for the heating element (when 230 V)
- Plug box for heating element probe (when 400 V)
9 Outside temperature probe
