widos SPA 600 - Description of the display

Starting and operating Chapter 5
08.05.2019 Working Instructions WIDOS SPA 600 Page 17 of 42
5.5. Description of the display
No. Denomination Function
1 Display - Displays the necessary parameters (for welding and
programming).
- Two values can be displayed at the same time.
2 Buttons for operation - Drag pressure measurement;
- Setting the pipe data and the project number;
- Setting the type of the machine;
- Printing the welding data;
- Diagnosis menu;
- Reset to the previous item of the menu.
1
2
