5.7.2. Dimension
In case ttraceability has been confirmed with „yes“, the display indicates.
Display:
2. line:
please read in
1st pipe
Either: Read in traceability of the first pipe via the bar code reading pen
Or: Simultaneously pres all buttons <+ / - / Enter>.
Then manually enter barcode of 1
st
pipe: Select first digit with <+/-> and jump to
the next digit with <Enter>.
Display:
2. line:
please read in
2nd pipe
Either Read in traceability of the second pipe via the bar code reading pen
Or: Simultaneously pres all buttons <+ / - / Enter>.
Then manually enter barcode of 1
st
pipe: Select first digit with <+/-> and jump to
the next digit with <Enter>.
Display:
2. line:
dimension
PE80 90 2.2
Display of:
Material, pipe diameter and wall thickness
Confirm the dimensions by pressing <Enter>, or interrupt the welding process by
pressing <C> and enter new dimensions.
Display:
2. line:
length pipe 1
+000.00 mm
Enter pipe lenght of the 1
st
pipe by <+ / - / Enter>.
Oder: Simultaneously pres all buttons <+ / - / Enter>.
Then manually enter barcode of 1
st
pipe: Select first digit with <+/-> and jump to
the next digit with <Enter>.
Display:
2. line:
length pipe 2
+000.00 mm
Either: Enter pipe lenght of the 1
nd
pipe by <+ / - / Enter>
Or: Simultaneously pres all buttons <+ / - / Enter>.
Then manually enter barcode of 1
st
pipe: Select first digit with <+/-> and jump to
the next digit with <Enter>.
