widos SPA 600 - Compensation of Mismatch; Bead up

Starting and operating Chapter 5
08.05.2019 Working Instructions WIDOS SPA 600 Page 25 of 42
5.7.5. Compensation of mismatch
Move pipe ends onto each other.
Display:
2. line:
alignment
T=210°C Pi=12
Display of:
Heating element temperature and actual pressure
After releasing the pressure, the following message appears:
Display:
2. line:
alignment OK?
T=210°C Pi=12
Display of:
Heating element temperature and actual pressure
If alignment of the pipes is correct, open the machine and confirm with button
<Enter>.
The mismatch may not exceed 10 % of the wall thickness.
In case of higher mismatch, readjust the pipe ends in the clamping devices and
repeat the planing process.
Abort the welding process by pressing button <C>.
5.7.6. Bead up
Insert the heating element into the basic machine. Move the pipes in the basic
machine onto each other.
Display:
2. line:
bead up
Ps=15 Pi=3
Display of:
desired and actual pressure
alternating with
Display:
2. line:
bead up
T=210°C Pi=3
Display of:
Heating element temperature and actual pressure
Slowly increase pressure until actual pressure = desired pressure (when
desired pressure is reached, a beep sound can be heard).
Maintain pressure until the pipe end lays completely at the heating element and
a bead according to DVS has been formed.
