Diagnosis program Chapter 6
08.05.2019 Working Instructions WIDOS SPA 600 Page 34 of 42
No. Signification
0027 - All internal values, such as printing offset, temperature straight line ramp, etc. are
displayed on the laptop
0030 - All stored weldings are deleted
When entering 0001, all weldings stored in the RAM memory up to that time are
deleted
0034 - Bit values from 0-1023 appear which will change together with the change of the
corresponding analog values
3 Heating element temperature PT 1000
4 Pressure (4-20 mA)
5 Environmental temperature
0063 - 0000 = mm / bar / °C
- 0001 = mm / bar / °F
- 0002 = mm / PSI / °C
- 0003 = mm / PSI / °F
- 0004 = inch / bar / °C
- 0005 = inch / bar / °F
