23WIKA operating instructions pressure transmitter, models E-10 and E-11
EN
Specications
Load in Ω
Output signal 4 ... 20 mA ≤ (supply voltage - 10 V) / 0.02 A
Output signal DC 0 ... 5 V > maximum output signal / 1 mA
Output signal DC 0.5 ... 4.5 V > 100k
Output signal DC 1 ... 5 V > 100k
Output signal DC 0 ... 10 V > maximum output signal / 1 mA
Voltage supply
Supply voltage → See product label
Max. power consumption 1 W
Dynamic behaviour
Settling time per IEC 61298-2 ≤ 2 ms
≤ 10 ms For model E-10 with measuring range ≤ 0 ... 25 bar at medium temperature < -30 °C
[-22 °F]
For model E-11
Short-circuit resistance S
+
vs. U
-
Reverse polarity protection U
+
vs. U
-
Insulation voltage DC 500 V
Material (wetted)
Model E-11 and E-10 with
measuring range ≤ 25 bar
Stainless steel
Model E-10 with measuring range
> 25 bar, NACE-compliant
■
Stainless steel
■
Elgiloy

Sealing → See “Process connection”
Material (in contact with the environment)
Case Stainless steel
Cable → See “Electrical connection”
9. Specications
