WIKA E-10 User Manual

11116552.11 EN/DE/FR/ES 03/2022
24 WIKA operating instructions pressure transmitter, models E-10 and E-11
EN
Specications
Pressure transmission medium
Model E-11 and E-10 with
measuring range ≤ 25 bar
Synthetic oil
Model E-10 with measuring range
> 25 bar
No pressure transmission medium
Permissible temperature ranges
1) 2) 3) 4)
Instruments per ATEX and IECEx Medium and
ambient temperature range
T6 -40 ... +60 °C [-40 ... +140 °F]
T5 -40 ... +75 °C [-40 ... +167 °F]
T4 ... T1 -40 ... +105 °C [-40 ... +221 °F]
Storage temperature range -40 ... +70 °C [-40 ... +158 °F]
Vibration resistance
per IEC 60068-2-6
10 g
Shock resistance
per IEC 60068-2-27
100 g (mechanical shock)
1) Restricted medium temperature range for oxygen applications: -20 ... +60 °C [-4 ... +140 °F]
2) For restrictions, see “Further details on: Process connection”
3) Restriction for version with protective cap: T4 ... T1, -40 ... +102 °C [-40 ... +215 °F]
4) For IP code IP67 the ambient temperature range is limited to -40 °C ... +80 °C [-40 ... +176 °F]
Options for specic media
Oil- and grease-free
Residual hydrocarbon < 1,000 mg/m²
Packaging Protection cap on the process connection
Oxygen, oil- and grease-free
Measuring ranges Max. 400 bar [5,000 psi]
Over pressure limit 2 times
Residual hydrocarbon Measuring ranges < 30 bar [435 psi] < 500 mg/m
2
Measuring ranges > 30 bar [435 psi] < 200 mg/m
2
Packaging Protection cap on the process connection
9. Specications
