25WIKA operating instructions pressure transmitter, models E-10 and E-11
EN
Options for specic media
Max. permissible temperature range -20 ... +60 °C [-4 ... +140 °F]
Elastomer sealing Max. -15 ... +60 °C [5 ... 140 °F] and max. 30 bar [435 psi] measuring range
Hydrogen On request
Process connection
Standard Thread size Max. measuring
range
Overpressure limit Sealing
Process connections for model E-10
EN 837 G ¼ B 1,000 bar [15,000 psi] 1,480 bar [21,400 psi] -
G ¼ female thread 1,000 bar [15,000 psi] 1,480 bar [21,400 psi] -
G ½ B 1,000 bar [15,000 psi] 1,480 bar [21,400 psi] -
DIN EN ISO 1179-2
(formerly DIN 3852-E)
G ¼ A 600 bar [8,700 psi] 858 bar [12,440 psi] NBR
ANSI/ASME B1.20.1 ⅛ NPT 400 bar [5,800 psi] 572 bar [8,290 psi] -
¼ NPT 1,000 bar [15,000 psi] 1,480 bar [21,400 psi] -
¼ NPT female thread 1,000 bar [15,000 psi] 1,480 bar [21,400 psi] -
½ NPT 1,000 bar [15,000 psi] 1,480 bar [21,400 psi] -
Process connections for model E-11
- G ½ B ush
(available for measuring
ranges 0 ... 2.5 to
0 ... 600 bar)
600 bar [8,700 psi] 600 bar [8,700 psi] NBR
400 bar [5,800 psi] 400 bar [5,800 psi] FPM/FKM
200 bar [2,900 psi] 200 bar [2,900 psi] EPDM
- G 1 B ush (available for
measuring ranges 0 ... 0.4
to 0 ... 1.6 bar)
1.6 bar [20 psi] 10 bar [145 psi] NBR
1.6 bar [20 psi] 10 bar [145 psi] FPM/FKM
1.6 bar [20 psi] 10 bar [145 psi] EPDM
9. Specications
