English
82 WILO SE 05/2015
8.5.2 Display menu mode The electronic module functions can be called via the menu structure.
The menu contains sub-menus on several levels.
The current menu level can be changed using “One level up” or
“One level down” menu items, for example, to change from menu
<4.1.0.0.> to <4.1.1.0>.
The menu structure is similar to structure of the chapters and sections
in these operating instructions: Section 8.5(.0.0) contains subsections
8.5.1(.0) and 8.5.2(.0); in the electronics module, menu <5.3.0.0>
contains menu sub-items <5.3.1.0> to <5.3.3.0>, etc.
The currently selected menu element can be identified by the menu
number on the display and the associated symbol.
Within a menu level, menu numbers can be selected sequentially by
turning the red button.
NOTE:
If the red button is not operated for 30 seconds at any position in
menu mode, the display returns to the status page.
Every menu level can contain four different element types:
“One level down” menu element The “One level down” menu element is indicated on the display by the
symbol shown here (arrow on the units display). If a “One level down”
menu element is selected, pressing the red button causes a change to
the next menu level down. On the display, the new menu level is indi-
cated by a menu number that has increased by one digit as a result of
the change; for example, menu <4.1.0.0> changes to menu <4.1.1.0>.
“Information” menu element The “Information” menu element is marked on the display by the sym-
bol shown here (standard symbol for “access disable”). If an “Informa-
tion” menu element is selected, pressing the red button has no effect.
When an “Information” menu element is selected, current settings or
measurements that cannot be changed by the user are displayed.
“One level up” menu element The “One level up” menu element is indicated on the display by the
symbol shown here (arrow on the symbol display). If a “One level up”
menu element is selected, briefly pressing the red button causes a
change to the next higher menu level. On the display, the new menu
level is indicated by the menu number. For example, when one returns
from menu level <4.1.5.0>, the menu number jumps to <4.1.0.0>.
NOTE:
If the red button is pressed for two seconds while a “One level up”
menu element is selected, the display jumps back to the status page.
“Selection/setting” menu element The “Selection/setting” menu element does not have a special label
on the display, but is identified graphically in these instructions by the
adjacent symbol.
If a “Selection/setting” menu element is selected, pressing the red
button will change to edit mode. In edit mode, flashing values can be
changed by turning the red button.
In some menus, acceptance of the input by pressing the red button
will be confirmed by the brief display of the “OK” symbol.
8.5.3 Display error page
If an error occurs, the error page will be shown on the display rather
than the status page. The value display shows the letter “E” and the
three-digit error code separated by a decimal point (Fig. 29).
±
E000
Fig. 29: Error page (status in the event of
an error)
E.025
