Grinder
Hex KeyCompression
Tool
Test Cell
Charge
Indicator
2 x Isopropyl Alcohol
(IPA) Wipes 99.8%
USB Drive
Battery Charger
12V Car Adaptor
Most Keys serve two functions. The first function is for selecting the operation to be performed, e.g. Sample
commands the meter to make a sample reading, Region commands the meter to accept the next two digits
as the code for the region, etc. The second function is as an alphanumeric keypad entry, i.e. for entering 0 to 9
and A to E. The key labelled ‘ENTER’, although also marked as ‘F’ does not enable the entering of ‘F’
as data and functions purely as the ENTER key at all times.
Key 8 is for changing between Field Mode & Lab Mode.
NOTE the default mode is Field Mode, Meter will always start in Field Mode
1.2 Keypad Layout
0 1 2 3
4 5 6 7
8 9 A B
C D E F
REGION BLOCK COMP COUPE
DATE TIME PG UP PG DN
SAMPLE TYPE
RESET ENTERTEST
1.2 Meter Layout (Inside)
Wiltronics Research Pty Ltd 7
561 DC1V1
To Next Page
