Explanations of the exemplary main screen display in 2m APRS operation:
- the built-in lithium ion battery is fully charged. The battery icon is completely filled in green.
A red triangle appears when charging
- To the right of the battery, “TX” appears in red when transmitting, while “RX” is green
when receiving, or there is no indicator when neither transmitting nor the squelch is open.
- Currently 10 satellites are used for position determination, GPS and Bluetooth are active.
- Your own call sign with SSID and the APRS symbol used
- Time (UTC) 15:16:40 (hours:minutes:seconds)
- The speed is 1kp/h
www.wimo.com - 10- ©Taner Schenker, 13. December 2022
The GPS icon flashes during GPS search.
If the GPS receiver has been temporarily deactivated to save energy (see "GPS
Powersave"), no GPS symbol will appear at this point.
A small "D" to the right of the number means that "Differential GPS" (WAAS/EGNOS) is
used via SBAS signal and the precision of the GPS position is more accurate.
