29
For the Service Technician
4.5.1 Values
The following values are displayed:
Temp. Boiler
The current boiler temperature is displayed in °C.
Temp. chamb.
The current temperature in the combustion chamber is dis-
played in °C.
Fan speed
The nominal speed of the blower is displayed in rpm.
Pos. Prim. airfl.
The position of the primary air choke is displayed in %.
Pos. Sec. airfl.
The position of the secondary air choke is displayed in %.
O2 signal
The O2 signal of the lambda sensor is displayed in %.
O2 heat current
The O2 heat current of the lambda sensor is displayed in A.
Temp. Exhaust
The current flue gas temperature is displayed in °C.
Fig. 63
4.5.2 Restart temperature
The blower switches off if the boiler temperature is too high. The restart tem-
perature is the temperature at which the blower switches back on and the boil-
er resumes normal heating operation.
Factory setting: 75 °C
Possible settings: 65 °C or 75 °C
Fig. 65
Temp. Boiler 68°C
Temp. chamb. 578°C
Fan speed 2150 rpm
Pos. Prim. airfl. 60%
Pos. Sec. airfl. 30%
O2 signal 18.1%
Back
Boiler temperature
for restart
Save
6655
Yes No
7755
75
°C
O2 heat current 2.5A
Temp. Exhaust 195°C
Back
4.5.3 Burnout
– automatic detection
Burnout characteristics are determined by MES thermal distribution mod-
ule WVF.
If only “Solid fuel operation” is set on the WVF, “Burnout” with embers
maintenance is undertaken. With all other settings on the WVF, a normal
burnout is undertaken.
– normal
A normal burnout is always undertaken, i.e. the wood is burnt as best as
possible until no more remains without
embers maintenance.
– Embers maintenance
Burnout with embers maintenance is always undertaken, i.e. basic embers
are maintained to make it easier to light up again.
Factory setting: normal
Fig. 66
Burnout
automatic detection
normal
Embers maintenance
Save
Yes No
Fig. 64
