8
Power consumption
WSC 310: min 3.2W
1+2
, typ. 4.8W
1+3
. At max load 300W
WSC 320: min 5.0W
1+2
, typ. 5.6W
1+3
. At max load 600W
1) no load: system operational but no actuators are running
2) min: 1 x break glass unit WSK 501 and 1 x smoke detector WSA 300
3) max load: 1 x break glass unit WSK 501, 4 x break glass unit WSK 503 and
10 x smoke detector WSA 300
Inrush current on primary site
70A<5ms
Max. 3 x WSC 310/320 per 10A supply group.
Circuit breaker “C” characteristic.
±24V change over time
min 500ms
Back-up batteries
WSC 310: 2 x WSA 007 (12V / 7Ah)
WSC 320: 2 x WSA 012 (12V / 12Ah)
Expected lifetime max 4 years, only use genuine WindowMaster batteries
Emergency power
>72 hours in accordance with EN 12101-10
Automatic smoke triggering
Smoke triggering when the temperature inside the compact unit exceeds 72ºC
Charging unit (integrated in WCA 3SS
card)
Charging voltage: 27.7 – 27.8V at 20ºC
Charging current: 1.7A, current limited
Priority
Smoke signal has always highest priority
Cable monitoring
±24V standard actuators with end of line module and smoke detectors are
monitored by closed-circuit
Actuators with MotorLink
®
and break glass units are monitored by data
communication
Back-up batteries are monitored by cyclic measuring
LED message OK, fault and alarm
Green
Yellow
Red
all OK
fault
fire
Reopening the actuators
Every 2.min. in 30min. after a SHE open (selectable) Pre-set: no reopening
Connection cable
Actuators
Other
components
flexible max 6 mm² / solide max 10 mm²
min 0,2mm² / max 1,5mm²
Operating conditions
-5°C - +40°C, max. 95% relative humidity (not condensing)
EN 12101-10: Operation class A, Environmental class 1, with IP value increased
to IP 54 (according to EN 12101-10 is min. IP 30 required)
Max actuator activation duration (duty
cycle)
ED 40% (4min. per 10min.)
Max allowed current drawn from the
battery when the primary power
source is disconnected
WSC 310: 10A
WSC 321: 20A
Max interruption time during switching
between power sources
<2.0sec
Break glass unit
Up to 10 break glass units type WSK 50x can be connected to the WCA 3SS, but
only 1 WSK 501 / 502 per line, meaning max 2 WSK 501 / 502 per panel.
Smoke detectors and ventilation keypads can only be connected to the break
glass units type WSK 501 / 502.
Up to 10 smoke detectors can be connected to each WSK 501 / 502, and 10
smoke detectors can be connected to the smoke detector input on the main
control card, which give a total maximum of 30 smoke detectors.
There is no limit on the number of ventilation keypads connected to the WSK 501
/ 502.
Smoke detectors and ventilation keypads cannot be connected to WSK 503 /
504.
Number of motor lines
2 x 10A motor line for ±24V standard or MotorLink
®
actuators
Material
Metal housing for surface mounting
Colour
Grey (RAL 7035)
