Window Master CompactSmoke WSC 320 - DIP Switch Configuration; 11 DIP Switch Configuration

20
11 DIP switch configuration
For easy configuration of the smoke panel the Standard version includes 16 DIP switches. The factory settings for all the DIP
switches is OFF.
DIP
switch
Description on
the panel
Description
DIP switch position
Possible
consequence
1.1
No 230V Close
230V power failure
ON: The windows close in case of power
failure.
OFF: No change in position in case of power
failure.
This function
becomes suspended
when DIP switch 1.2
is ON.
1.2
Moment. act.
(Totmann) Close
Momentary action
CLOSE
(comfort ventilation)
ON: The window actuators run for as long as
the comfort keypad is pressed.
OFF: The windows close completely when
pressing the comfort keypad once.
This function
becomes suspended
when DIP switch 1.1
is on.
1.3
Moment. act.
(Totmann) Open
Momentary action
OPEN
(comfort ventilation)
ON: The window actuators run for as long as
the comfort keypad is pressed.
OFF: The windows open completely when
pressing the comfort keypad once.
1.4
Error Alarm
System fault triggers
alarm
ON: In case of fault (yellow diode lights), the
system will go into Alarm and the windows will
open.
OFF: Only fault indication
1.5
Re-triggering
(VdS)
VdS triggering by
alarm
ON: when the alarm is triggered the actuators
will, in accordance with VdS 2581, for a
duration of 30min be triggered to shortly
reverse and open every second minute.
OFF: Normal alarm
1.6
Smoke detc. (B)
Close
Smoke detector –
CLOSE
(primarily used in
Switzerland)
ON: When the alarm is triggered by a smoke
detector, the windows will close in all smoke
zones. A following operation of a break glass
unit will leave the system in alarm but trigger
the actuators to open the windows. Break
glass units have higher priority than smoke
detectors.
OFF: regardless if the alarm is triggered by
smoke detectors or break glass units, the
window actuators will open the windows
1.7
24/48V
24V / 48V input active
(primarily used in
France)
ON: The 24V / 48V input becomes active. Only
one smoke zone is possible.
OFF: the 24V / 48V input is deactive. Up to 2
smoke zones are possible.
1.8
Actuator 180
sec.
Actuators with higher
run time than 61sec
(both closing and
opening time)
ON: The panel will leave actuator voltage on
for 180 sec. Used for non EN 12101-2
actuators.
OFF: Used with actuators with a run time of
less than 60 sec (normal)
2.1- 2.3
Run time limit 1
Run time limit 2
Run time limit 3
Run time limitation
(OPEN)
(comfort ventilation)
The opening run time of the window actuators
can be limited via the DIP switch 2.1 - 2.3.
When using 24V DC
actuators, a full close
cycle must be carried
out (2 x run time ca.
120 sec.). Activated
by pressing the
“Close all windows”
button and wait for
min 2min. This resets
the current position.
DIP switch
Run time
2.1
2.2
2.3
No run time
limitation (normal)
OFF
OFF
OFF
83% (~ 50sec)
ON
OFF
OFF
67% (~ 40sec)
OFF
ON
OFF
50% (~ 30sec)
ON
ON
OFF
42% (~ 25sec)
OFF
OFF
ON
33% (~ 20sec)
ON
OFF
ON
25% (~ 15sec)
OFF
ON
ON
17% (~ 10sec)
ON
ON
ON
