4 Accessories and spare parts
Accessories
Back-up battery for WSC 310 - 7Ah (2 x WSA 007 per panel )
WSA 007
Back-up battery for WSC 320 - 12Ah (2 x WSA 012 per panel)
WSA 012
Break glass unit, primary, with data communication, PVC housing. With input for smoke detector and
comfort keypads. Only one unit per line.
x = colour of the housing: 1=red, 2=yellow, 3=grey, 4=blue, 5=orange
WSK 501 000x
Break glass unit, primary, with data communication, metal housing. With input for smoke detector and
comfort keypads. Only one unit per line.
x = colour of the housing: 2=yellow, 3=grey, 5=orange
WSK 502 000x
Break glass unit, primary, with data communication, PVC housing. No input for smoke detector or
keypad. Max five units per line.
x = colour of the housing: 1=red, 2=yellow, 3=grey, 4=blue, 5=orange
WSK 503 000x
Break glass unit, primary, with data communication, metal housing. No input for smoke detector or
keypad. Max five units per line.
x = colour of the housing: 2=yellow, 3=grey, 5=orange
WSK 504 000x
Smoke detector
WSA 300
Rain sensor
WLA 331
Rain/wind speed sensor
WLA 330
End of line motor module
WSA 510
End of line smoke detector module (10kΩ resistor), 10 pcs.
WSA 501
Cables for smoke ventilation – see separate data sheet for further information
WLL 8xx
Spare parts
10A power supply unit for WSC 310
WCA 3P1
20A power supply unit for WSC 320
WCA 3P2
Main control card for Standard version WSC 310 / WSC 320 incl. cover + 2 end of line modules
(WSA 510)
WCA 3SS
Plastic cover for the main control card in the WSC 310 / WSC 320 Standard version
WCA 302
Lock cylinder incl. 2 keys for WSC 310/320 panel
WCA 307
Replacement glass for break glass units type WSK 501 / 502 / 503 / 504, 5 pcs.
WSK 397
Keys for break glass units type WSK 501 / 503, 5 pcs.
WSK 398
Keys for break glass units type WSK 502 / 504, 1 pcs.
WSK 453
Lockable replacement PVC housing for break glass unit
x=colour of the housing: 1 = red, 2 = yellow, 3 = grey, 4 = blue, 5 = orange
WSK 399 000x
Back-up battery cable kit for WSC 310 / 320 (cable between WCA 3SP / 3SS and the batteries and
between the batteries)
WSA 330 0101
20A battery fuse. The battery fuse on the WCA 3SP/3SS, 10 pcs
WSA 331 0101
5 Technical data
Technical data
Output current (nominal)
WSC 310: 10A / WSC 320: 20A
Secondary voltage
Voltage 24V DC (±15%)
Open circuit voltage (no load) 27.6V DC @ 20°C
Ripple at max load max. 6% (3.5Vpp)
Motor lines
Motor groups
Smoke zones
2 motor lines – a line can be either ±24V standard motor line or MotorLink
®
motor
lines - in max 2 motor groups and max 2 smoke zones
Primary voltage
WSC 310: 230V AC, 50Hz (85-264V AC, 47-63Hz)
WSC 320: 230V AC, 50Hz (85-264V AC, 47-63Hz)
