16 86317500 CHARIOT SCRUBBER
Operations
Scrub Controls
1. FUNCTION MODE SWITCH
The first two positions are for transport only. See drive controls section.
A1 - Daytime cleaning/light cleaning
This mode is used for light cleaning. In this mode the machine will propel at a maximum of medium speed. The
scrub deck will automatically lower to a lower down pressure setting. The water will flow at a low rate. Water will
automatically shut off in neutral and restart when pressure resumes. The squeegee will automatically lower and
vacuum will continue on at a low flow. (Squeegee will continue to lower and the vacuum will continue to run in
neutral. The squeegee will raise in reverse.)
A2 - Medium scrub level cleaning
This mode is used for medium level cleaning. In this mode the machine will propel at a maximum of medium. The
scrub deck will lower at a medium down pressure. The water will flow at a medium rate. The vacuum will flow at a
a medium.
