86317500 CHARIOT SCRUBBER 31
Maintenance
1. Squeegee
2. Squeegee Deflection Adjustment Knobs
3. Squeegee Level Indicator
4. Squeegee Pitch Adjustment Rod
5. Squeegee Pitch Adjustment Lock Nut
6. Squeegee Retainer Knob
1
2
3
4
5
6
Squeegee
