50 86317500 CHARIOT SCRUBBER
Maintenance
Transporting
Pushing Machine
The machine may be pushed for short distances at
speeds not to exceed 5 mph. Be careful to avoid
damaging machine. The machine may be pushed by
hand from the rear.
NOTE: To avoid damage caused by regenerative
voltage, disconnect traction motor before towing or
pushing machine.
Machine Tie-Downs
There are two tie points located at front and each side
of foot box frame and two at the front side of frame.
Tie-down devices must be of the proper type and
strength. The combined strength of all tie-downs must
be strong enough to lift two times the weight of the
machine. Tie-downs must be positioned to prevent the
machine from moving forward, backward, or either side
to side. Use all four corners of the machine with the tie-
downs running out opposite directions. Tie-downs must
be attached to the transporting vehicle securely.
Preparation for Loading/Unloading Trailer
Before loading or unloading machine from trailer,
remove squeegee, scrub deck, side skirts or side
squeegees, Aqua-Mizers and scrub brushes (pads) to
eliminate interference with tie-downs.
Scrub head must be in the up position before loading.
When transporting the machine on a trailer or in a truck,
in addition to using tie-downs, be sure to set the parking
brake, and block the tires to prevent the machine from
rolling
