19
Operations
Vacuum only mode
This mode is used for picking up solution only. The brush and water will both be up and off. In
this mode the machine will propel at fast speed. The squeegee is lowered and the vacuum
will come on.
Double Scrub cleaning (with chemical metering on equipped models)
This mode is used for putting down solution and scrubbing without picking it back up. The
squeegee is set manually by connecting the two double scrub support cables. In this mode
the machine will propel at a slow speed. The scrub deck will lower. The solution will flow. The
brush and water will shut off when the machine is in neutral. They will resume when propelling
is resumed.
Light cleaning with chemical metering
Chemical dilution rate to be set by chemical metering selection switch.
Deep cleaning with chemical metering
Chemical dilution rate to be set by chemical metering selection switch.
86398220 Operators Manual - Chariot-2 iScrub 20
