49
Maintenance
Circuit Protection
Circuit Breakers
Circuit breakers interrupt the flow of power in the event of an electrical overload. When a circuit breaker is tripped,
reset it by pressing the exposed button. If a circuit breaker continues to trip, the cause of the electrical overload
should be found and corrected.
1.5 Amp protects the brush deck lift actuator, horn & controller.
18 Amp protects the vacuum motor.
12 Amp protects the brush motor - Disk / Orbital.
25 Amp protects the brush motor - Cylindrical.
86398220 Operators Manual - Chariot-2 iScrub 20
