Winegard ConnecT 2.0+ User Manual

11
For help, email help@winegard.com or call 1-800-320-9992
SWAPPING THE SIM CARD (4G LTE Systems Only) cont.
OPERATION
1) Turn the ConnecT 2.0
+
on.
2) Turn on the WiFi enabled device(s) that you want to connect and scan for
wireless networks. (It may take a few minutes for the network to appear).
It is recommended to set your device(s) to automatically connect with
the Winegard ConnecT 2.0
+
.
3) The label located on the front of this manual lists the unique default SSID
and password. Select this WiFi signal from the list of wireless networks
and connect. Once the correct SSID has been selected, enter the
password.
4) Once connected, open an Internet
browser and type 10.11.12.1 into the
address bar and press Enter. This will
take you to the Admin Login Screen.
Login using:
Username: admin Password:
check the front of this manual for the
password. See figure at right.
5) Next, you will need to connect to the
internet in order to download the
correct cellular provider’s firmware.
Select WiFi Only and click the
SELECT button.
6) Click the SCAN FOR WIFI button and
select one of the usable WiFi networks.
7) Once connected to the internet, under the NAVIGATE TO PAGE field,
click on the drop down menu and select Advanced Settings followed by
clicking the SELECT button.
8) In the Advance Settings screen, click on the CHANGE PROVIDER button.
See figure 10.
9) Verify that the correct cellular provider is listed in the CELLULAR
PROVIDER field and then enter either the correct APN from the table
below, or the one that your cellular provider provided you when you
requested your SIM card in the CELLULAR APN field. Also, be sure that
the Winegard APN check box is NOT checked. See figure 11.
10) Click on the CHANGE PROVIDER button.
11) Once the download is completed, click on the PROCEED button (if
available) to start the flash procedure. Next, click on the 4G/LTE ONLY
Internet Access option on the main Status screen. Your internet status
should change to Connected to “Your Provider”. See figure 12.
12) You are ready to use the internet with your own data plan!
Figure 11
Disclaimer: Although every effort has been made to ensure that the information in
this manual is correct and complete, no company shall be held liable for any errors or
omissions in this manual. Changes and technological advances are continuously being
made in the wireless market. Information provided in this manual was accurate at time
of printing. If the ConnecT 2.0
+
antenna does not function as expected, please contact
Winegard Company at 1-800-320-9992, email help@winegard.com, or visit our website
at www.winegard.com/connect.
Figure 10
Figure 12
CELLULAR PROVIDER APN (ACCESS POINT NAME)
AT&T BROADBAND
VERIZON vzwinternet
