WinGD WARTSILA RT-flex58T-E - Page 232

Maintenance3303−4/A1
RT-flex58T-E
Winterthur Gas & Diesel Ltd.
2/ 7
VIEW
I −> Piston suspended to cylinder block:
WCH01031
GF 94333B
94040-M20 (RC1)
GF 94333A
10
4
94040−M20 (RC1)
VIEW
II −> Stop plate mounted and
top end bearing cover locked against tilting:
WCH00390
94040−M30 (RC2)
94040−M20 (RC1)
GF 94335
7
8
VIEW III −> Bottom end bearing cover replaced with holder:
WCH00317
94334
1
3
2013 / V2
Removal and Fitting
