Maintenance
3303−4/A1
RT-flex58T-E
Winterthur Gas & Diesel Ltd.
7/ 7
3. Fitting
Fitting the connecting rod is carried out analogously to the removal, but in reverse
sequence, whereby attention must be paid to the instructions 3303−1 to 3303−3.
For the assembly bearings and bearing pins must be in perfect condition. They
must be smeared lavishly with fresh bearing oil.
Measure the clearances according to Clearance Table 0330−1 ’Top and bottom
end bearings to connecting rod’.
Attention! Always fit toggle lever in such a way that its curvature stands upwards.
After completing the work retaining pins 94323 and all other tools must be removed
immediately from the crankcase.
2013
Connecting Rod: Removal and Fitting
