Maintenance
5562−1/A1
RT-flex58T-E
Winterthur Gas & Diesel Ltd.
3/ 3
4. Cleaning the filter
⇒ Remove oil inlet pipe ’OE’ and union 14.
⇒ Loosen filter 13 and clean it. If necessary replace it.
⇒ Oil the filter, screw it into cover 12 and apply a torque of 10 Nm.
C
BA
OE
OIL
WCH00763
2
BE
11
3
4
9
5
8
6
7
14 12 13
26 22
10
21
FUEL OIL
5. Storage on board
The spare parts must be carefully protected against corrosion.
D The PCV has to be free from any dirt, oil and grease.
D Apply coating liquids (e.g. Tectil 506, ISOTEC 337 or similar) on the surfaces
to be preserved.
D All blind holes and tapped holes must be plugged.
Especially consignments transported overseas must be well protected against ad-
verse climatic conditions (intense cold, rain, high humidity, etc.) and kept in a
closed box.
2013
Fuel Pressure Control Valve: Removal, Fitting, Dismantling and Assembling
