Maintenance9403−3/A1
RT-flex58T-E
Winterthur Gas & Diesel Ltd.
4/ 9
Tool GF 94180 Pre-tensioning jack for tie rod
1 Piston 7 Vent screw
2 Back-up ring
O-ring
Sealing ring
8 Adapter piece
3 9 Closing valve
4 Cylinder 10 Eyelet
5 Back-up ring
O-ring
Sealing ring
6
GF 94180−KJ K
it with back-up and O-rings
for pre-tensioning J
ack
1
4
MAX. STROKE 42 MM
2
3
5
6
GF 94180−KJ
7
8
9
10
WCH00975
2013
Hydraulic Pre-tensioning Jacks: Storing, Servicing and Maintenance
