Tool CF 94215 Pre-tensioning jack for elastic bolt to cylinder cover
1 Piston 7 Vent screw
2 Back-up ring
O-ring
Sealing ring
8 Adapter piece
3 9 Closing valve
4 Cylinder 10 Eyelet
5 Back-up ring
O-ring
Sealing ring
6
CF 94215−KJ K
it with back-up and O-rings
for pre-tensioning J
ack
4
2
3
5
6
1
CF 94215−KJ
8
WCH03504
MAX. STROKE 25 MM
9
7
